Data Sheet
Product Code: MKP180
Product Description: 2-Way Push-on Push-off LED Replacement Dimmer Module Kit 1 x 15-180W (Max 20 LEDs)
Range: Module
Finish: Matrix
Product Category: V-Com Module
Barcode: 5021575193336
Dimensions: 53x28x42mm (Click here to see full dimensions)
Net Weight: 48g
Gross Weight: 50g
Fixing Centres: N/A
Depth from Mounting Face:
Recommended Back Box Depth: N/A
Operating Voltage: 230v 50Hz
Maximum Load Rating: LED; 180W (Max. 20 LEDs)
Maximum Current Rating: 0.78A
Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²
Product Features
Can be used to replace dimmer modules in existing faceplates or in the Matrix dimmer grid system
V-Com intelligent TRIAC leading edge dimming technology
Soft start feature and intelligent overload protection
Suitable for many dimmable LED lamps
Suitable for all Matrix Kits
Intended Applications: Indoor Use Only. Domestic lighting circuits.
Safety Advice: Not suitable for use with wire-wound or toroidal transformers or electric motors. Do not overload.
Applicable Safety Standard: BS EN 60669-2-1
Commodity Code: 8517180000
10 YEAR GUARANTEE
BRITISH MADE
All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of Issue: 07th March 2021 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
