VARILIGHT Specialist Modules
The below modules are to be used in 2-way and multi-way circuits, usually in conjunction with a Push On/Off Dimmer to retain the aesthetics of a dimmerswitch. They are designed to be easily substituted into the back of an existing product. You can do this by removing the knob (and the plate, on a Screwless product) and unscrewing the nut. The dimmer will then be easily removable from the back of the product and switched with one of the two modules below.
Z0H0
2-Way Push On/Off Switch ModuleTo be used where there are two switches controlling the same light or set of lights, usually where one switch is a dimmer. If you are using 2-way push on/off dimmerwitches you can replace either one of the switches with this replacement switch module which looks like a dimmer.
MPINT
Intermediate Push On/Off Switch ModuleTo be used where there are three or more switches controlling the same light or set of lights, usually where one switch is a dimmer. The most typical example of this might be in a hallway, when perhaps there is a switch at the front door, a switch at the bottom of the stairs and one at the top of the stairs, all controlling the same hall light. On this circuit the middle switch (usually the one at the bottom of the stairs) will be an intermediate switch. This can be extended to four or more switches.
With these two products, you have the flexibility to install intermediate and 2-way switches that look like dimmers. Only one of these switches can be a dimmer but you can use VARILIGHT touch and remote dimmers, V-Pro IR and Eclique2, to dim from all switch locations.
VARILIGHT 2-Way and Interemdiate modules are available in the following formats:
- Replacement Modules
- PowerGrid Modules
- Multi-Grid Modules for MK Crabtree and Schneider/GET grid
We are also able to create Bespoke items to your specification. Click here for more information.
