Data sheet: XDL2LWS

2-Gang 10A 1- or 2-Way Rocker Switch, Part M Black & White (XDL2LWS)

Data sheet

XDL2LWS 2-Gang 10A 1- or 2-Way Rocker Switch

Name: 2-Gang 10A 1- or 2-Way Rocker Switch
Brand: VARILIGHT
SKU: XDL2LWS

Double Rocker Light Switch 2-Way

Range Part M Finish Black-White

Product features

1- or 2-Way switching
Suitable for controlling both mains and low voltage lighting
10A rated
Firm, positive switching action
High-contrast black faceplate, just 4mm deep with brass screws, fits a 25mm back box

Product

Product code: XDL2LWS
Category: Rocker Switches
Range: Part M
Finish: Black-White
Insert / knob colour: Large White Rockers
Barcode: 5021575010497

Size and fitting

Dimensions: 86x86x25mm
Faceplate depth: 4mm
Fixing centres: 60.3mm
Depth from mounting face: 17.4mm
Recommended back box depth: 25mm
Net weight: 126g
Gross weight: 128g

Electrical

Operating voltage: 230V 50Hz
Maximum load rating: 10A
Maximum current rating: 10A
Terminal (Live): 3.3mm, capacity 3 x 1.5mm²
Terminal (Earth): 3.3mm, capacity 3 x 1.5mm²

Safety and compliance

Intended applications: Indoor Use Only. Domestic lighting circuits. Do not use masking tape on any decorative products, or install on damp plaster.
Safety advice: Product Must Be Earthed.
Applicable safety standard: BS EN 60669-1
Commodity code: 85365007

Declaration of Conformity

Part M collection

The Part M range offers high-contrast wiring accessories that help visually impaired users locate and operate switches and sockets more easily, supporting compliance with Part M of the Building Regulations. Each product pairs a black faceplate with contrasting white rockers and inserts, and extra large rockers are available on many of the switches for easier operation.

Black-White finish

A black faceplate with contrasting white rockers, inserts and dimmer knobs gives the high visual contrast recommended by Part M of the Building Regulations, helping visually impaired users find and operate switches and sockets.

All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of issue: 11th November 2026. © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
