Data sheet: XNU65B

2-Gang 65W USB C+C Charger (Single Plate), Classic Satin Chrome (XNU65B)

Data sheet

XNU65B 2-Gang 65W USB C+C Charger (Single Plate)

Range Classic Finish Satin

Product features

Extra fast charging at 65W from twin USB-C ports
Power shared intelligently so both devices charge at optimum speed
Supports Power Delivery 3.0, Quick Charge 3.0, AFC, FCP and Apple Fast Charge
100-240V AC input for use anywhere in the world
Frees up mains sockets for other appliances
Bevel-edge faceplate, 8mm deep with chrome screws, fits a 47mm back box

Product

Product code: XNU65B
Category: USB C Charging Ports
Range: Classic
Finish: Satin
Insert / knob colour: Black Insert
Barcode: 5021575932539

Size and fitting

Dimensions: 91x91x47mm
Faceplate depth: 8mm
Fixing centres: 60.3mm
Depth from mounting face: 39mm
Recommended back box depth: 47mm
Net weight: 136g
Gross weight: 138g

Electrical

Operating voltage: 100-240VAC 50/60Hz
Terminal (Live): 4mm
Terminal (Neutral): 4mm
Terminal (Earth): 3.3mm, capacity 3 x 1.5mm²

Safety and compliance

Intended applications: Indoor Use Only. Domestic electrical circuits.
Safety advice: Output: USB C: 5V-3A/9V-3A/12V-3A/15V-3A/20V-3.25A (for a single device), USB C + USB C: 5V-3A (for multiple devices). Product Must Be Earthed.
Applicable safety standard: BS 1363-2; EN 50563:2011
Commodity code: 85366990

Declaration of Conformity

Classic collection

The Classic range is a contemporary take on a raised profile faceplate. The bevel-edge design is a timeless style, which will pair beautifully with any interior.

Satin finish

The Satin finish has a subtle sophistication with its soft sheen and understated elegance, which will enhance most interior design schemes. Black or white inserts blend seamlessly, with the option of polished chrome rockers for a luxury feel.

All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of issue: 11th November 2026. © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
