Data Sheet
Product Code: XO45NW
Product Description: 45A Cooker Switch with Neon (Vertical Twin Plate, Red Rocker)
Range: Value
Finish: Polar White
Product Category: Cooker Switches
Insert/Knob Colour: White Insert
Barcode: 5021575050363
Dimensions: 85x146x35mm
Faceplate Depth: 5mm
Net Weight: 259g
Gross Weight: 262g
Fixing Centres: 120.6mm
Depth from Mounting Face:
Recommended Back Box Depth: 35mm
Operating Voltage: 230v 50Hz
Maximum Load Rating: 45A
Maximum Current Rating: 45A
Terminal (Live) Diameter: 6.4mm; Capacity: 2 x 10mm²
Terminal (Neutral) Diameter: 6.4mm; Capacity: 2 x 10mm²
Product Features
Double pole switching
Neon indicator light
Double sized vertical plate
Durable white plastic faceplate is anti-bacterial and fully biodegradable
Value Collection
The Polar White plastic range offers exceptional value. Push-fit screw covers give the face plate a uncomplicated aesthetic at an affordable price point.
Intended Applications: Indoor Use Only. Domestic power supply.
Applicable Safety Standard: BS EN 60669-1
Commodity Code: 85389091
All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of Issue: 21st June 2025 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
