Data Sheet
Product Code: XO8W
Product Description: 1-Gang TV Socket, Co-Axial
Range: Value
Finish: Polar White
Product Category: TV and Telephone Sockets
Insert/Knob Colour: Plain Insert
Barcode: 5021575050721
Dimensions: 85x85x23mm
Faceplate Depth: 5mm
Net Weight: 96g
Gross Weight: 98g
Fixing Centres: 60.3mm
Depth from Mounting Face:
Recommended Back Box Depth: 16mm
Operating Voltage: N/A
Maximum Load Rating: N/A
Maximum Current Rating: -
Product Features
TV socket for use with male co-axial plugs
Durable white plastic faceplate is anti-bacterial and fully biodegradable
Value Collection
The Polar White plastic range offers exceptional value. Push-fit screw covers give the face plate a uncomplicated aesthetic at an affordable price point.
Intended Applications: Indoor Use Only. Data circuits.
Applicable Safety Standard: BS 5733
Commodity Code: 85366910
All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of Issue: 19th June 2025 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
