Click below to print the data sheet for YT40DC24
Further information:
Data Sheet
Product Code: YT40DC24
Product Description: 230V AC to 24V DC Dimmable Converter for LED Strip (max 40W)
2 YEAR GUARANTEE
MADE IN THE EU
Product Category: Transformers and Drivers
Insert/Knob Colour:
Barcode: 5021575001358
Dimensions: 167x54x23mm
Net Weight: 178g
Gross Weight: 180g
Fixing Centres: N/A
Depth from Mounting Face:
Recommended Back Box Depth: N/A
Operating Voltage: 230v 50Hz
Maximum Load Rating: 40W
Maximum Current Rating: 230V AC: 0.2A / 24V AC: 3.5A
Terminal (Live) Diameter: N/A; Capacity: N/A
Terminal (Neutral) Diameter: N/A; Capacity: N/A
Terminal (Earth) Diameter: N/A; Capacity: N/A
Product Features
Dimmable power supply for 24V d.c LED strip up to a maximum of 40W
Enhanced performance with all 24V LED lamps up to a maximum of 30W
Auto-resetting overload protection and over-temperature
Short circuit protection
Intended Applications: Indoor Use Only. Domestic lighting circuits.
Applicable Safety Standard: EN 61347-1, EN 61347-2-2, EN 61547, EN 55015 & EN 61000-3-2
Commodity Code: 85043180
Date of Issue: 08th December 2023 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
