Data Sheet

Product Code: IDQI402MS

This product is no longer available for purchase

Product Description: 2-Gang 1-Way Remote Control/Touch Master Dimmer 2 x 40-400W

Range: Screwless

Finish: Premium White

Product Category: Halogen Dimmers

Insert/Knob Colour: Chrome Buttons

Barcode: 5021575190519

Dimensions: 86x86x30mm

Faceplate Depth: 4mm

Net Weight: 178g

Gross Weight: 180g

Fixing Centres: 60.3mm

Depth from Mounting Face: 26.3mm

Recommended Back Box Depth: 35mm

Operating Voltage: 220/250V AC

Maximum Load Rating: Halogen: 400W

Maximum Current Rating: 1.7A

Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²

Terminal (Earth) Diameter: 3.3mm; Capacity: 3 x 1.5mm²

Intended Applications: Indoor Use Only. Domestic lighting circuits. Do not use masking tape on any decorative products, or install on damp plaster.

Safety Advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload. Product Must Be Earthed.

Applicable Safety Standard: BS EN 60669-2-1

Commodity Code: 85365007

Declaration of Conformity

Product Features

  V-Plus intelligent dimming technology

  Touch control or remote control from dedicated handset or spare button on an existing handset (e.g. TV remote)

  Soft start feature and intelligent overload protection

  Sleek, low-profile screwless faceplate

Screwless Collection
Screwless Low Profile: minimalist design with clip-on faceplates and hidden fixings for a smooth, modern look. The Screwless Metal faceplates are expertly manufactured in the UK to the highest standard.

Premium White Finish
The Premium White finish is created using a high gloss polycarbonate and is beautifully presented on low profile screwless faceplate, paired with chrome inserts and featuring hidden fixings, contributing to its understated appeal. Varilight Decorative wiring accessories are British made and covered by the Varilight lifetime guarantee.
