Data Sheet

Product Code: IFVP701

This product is no longer available for purchase

Product Description: 1-Gang 2-Way Push-On/Off Rotary Dimmer 1 x 60-700W

Range: Ultraflat

Finish: Polished Brass

Product Category: V-Plus Dimmer

Insert/Knob Colour: Brass Knob

Barcode: 5021575640687

Dimensions: 89x89x48mm

Faceplate Depth: 1mm

Net Weight: 166g

Gross Weight: 168g

Fixing Centres: 60.3mm

Depth from Mounting Face: 30.1mm

Recommended Back Box Depth: 35mm

Operating Voltage: 230v 50Hz

Maximum Load Rating: Halogen; 700W

Maximum Current Rating: 3A

Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²

Terminal (Earth) Diameter: 3.3mm; Capacity: 3 x 1.5mm²

Intended Applications: Indoor Use Only. Domestic lighting circuits.

Safety Advice: Not suitable for motors or fans. Do not overload. Product Must Be Earthed.

Applicable Safety Standard: BS EN 60669-2-1

Commodity Code: #N/A

Declaration of Conformity

Product Features

  V-Plus intelligent dimming technology

  Ideal for mains and low voltage halogen lighting

  Soft start feature and intelligent overload protection

  Contemporary, ultra-slim faceplate

Ultraflat Collection
The Ultraflat range features a slim profile faceplate and provides an understated modern look. Cut from high quality stainless steel, this minimalist range will enhance any interior design scheme.

Polished Brass Finish
The elegant Polished Brass finish features matching polished brass rockers with an option of black or white inserts. Varilight?s decorative wiring accessories are British made and covered by the Varilight lifetime guarantee.
