Data Sheet

Product Code: IQI402M

This product is made to order

Product Description: 2-Gang 1-Way Remote Control/Touch Master Dimmer 2 x 40-400W

Range: White

Finish: White Plastic

Product Category: Halogen Dimmers

Insert/Knob Colour: Chrome Buttons

Barcode: 5021575580440

Dimensions: 85x85x30mm

Faceplate Depth: 11mm

Net Weight: 138g

Gross Weight: 140g

Fixing Centres: 60.3mm

Depth from Mounting Face: 18.8mm

Recommended Back Box Depth: 25mm

Operating Voltage: 220/250V AC

Maximum Load Rating: Halogen: 400W

Maximum Current Rating: 1.7A

Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²

Intended Applications: Indoor Use Only. Domestic lighting circuits.

Safety Advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload.

Applicable Safety Standard: BS EN 60669-2-1

Commodity Code: 85365007

Declaration of Conformity

Product Features

  V-Pro Multi-Point intelligent dimming: control the lights from every location on the circuit

  Dims 40-400W of lighting per circuit with no minimum load and no maximum number of lamps

  Touch to dim from the tactile touch pad, or use an infrared handset, even a spare button on the TV remote

  One master with any number of supplementary controllers on the circuit

  Retrofits with standard 3 core and earth wiring

  Programmable driving modes and adjustable minimum brightness for wider LED compatibility

  Unlock LightScene with the YRE8 handset: 4 lighting scenes and 4 circuits controlled individually

  Durable white plastic faceplate, 11mm deep, fits a 25mm back box

White Collection
The White range is the practical choice: a durable white plastic faceplate that suits any interior and any budget, with the same VARILIGHT dimming technology and build quality found across our decorative ranges.

White Plastic Finish
A durable white plastic faceplate with matching white rockers and dimmer knobs. A practical, easy-to-match finish for any room.
