Data Sheet

Product Code: ISI402M

This product is made to order

Product Description: 2-Gang 1-Way Remote Control/Touch Master Dimmer 2 x 40-400W

Range: Value

Finish: Matt Chrome

Product Category: Halogen Dimmers

Insert/Knob Colour: Chrome Buttons

Barcode: 5021575590449

Dimensions: 88x88x30mm

Faceplate Depth: 7mm

Net Weight: 178g

Gross Weight: 180g

Fixing Centres: 60.3mm

Depth from Mounting Face: 20.4mm

Recommended Back Box Depth: 25mm

Operating Voltage: 220/250V AC

Maximum Load Rating: Halogen: 400W

Maximum Current Rating: 1.7A

Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²

Terminal (Earth) Diameter: 3.3mm; Capacity: 3 x 1.5mm²

Intended Applications: Indoor Use Only. Domestic lighting circuits. Do not use masking tape on any decorative products, or install on damp plaster.

Safety Advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload. Product Must Be Earthed.

Applicable Safety Standard: BS EN 60669-2-1

Commodity Code: 85365007

Declaration of Conformity

Product Features

  V-Plus intelligent dimming technology

  Touch control or remote control from dedicated handset or spare button on an existing handset (e.g. TV remote)

  Soft start feature and intelligent overload protection

  Curved edge faceplate

Value Collection
The Classic range is a contemporary take on a raised profile faceplate. The bevel-edge design is a timeless style, which will pair beautifully with any interior. Each plate is expertly manufactured in the UK to the highest standard.

Matt Chrome Finish
Matt Chrome offers unbeatable value for those seeking a beautiful Decorative finish at a great price point. Choose between black, white or matching metal rockers. Varilight Decorative wiring accessories are British made and covered by the Varilight lifetime guarantee.
