Product Code: KQP182W
This product is made to order
Product Description: 2-Gang 2-Way V-Com Push On/Off Rotary LED Dimmer 2 x 15-180W
Range: White
Finish: White Plastic
Product Category: LED Dimmers
Insert/Knob Colour: White Knob
Barcode: 5021575582369
Dimensions: 85x85x47mm
Faceplate Depth: 11mm
Net Weight: 146g
Gross Weight: 148g
Fixing Centres: 60.3mm
Depth from Mounting Face: 14.6mm
Recommended Back Box Depth: 25mm
Operating Voltage: 230v 50Hz
Maximum Load Rating: LED; 180W
Maximum Current Rating: 0.8A
Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²
Product Features
V-Com intelligent TRIAC leading edge dimming technology
Soft start feature and intelligent overload protection
Adjustable minimum brightness setting and choice of driving modes to optimise the dimming performance of a given LED lighting load
Durable white plastic
Intended Applications: Indoor Use Only. Commercial & domestic lighting circuits including many dimmable LEDS.
Safety Advice: Not suitable for use with non-dimmable fluorescent bulbs and tubes, wire-wound or toroidal transformers or electric motors. Do not overload.
Applicable Safety Standard: BS EN 60669-2-1
Commodity Code: 85365005
