Data Sheet

Product Code: TDVDR1001S

This product is no longer available for purchase

Product Description: 1-Gang 1-Way Rotary Dimmer 1 x 200-1000W (Twin Plate)

Range: Screwless

Finish: Polished Brass

Product Category: V-Dim Dimmer

Insert/Knob Colour: Brass Knob

Barcode: 5021575969894

Dimensions: 86x147xmm

Faceplate Depth: 4mm

Net Weight: 249g

Gross Weight: 252g

Fixing Centres: 120.6mm

Depth from Mounting Face: 28.4mm

Recommended Back Box Depth: 35mm

Operating Voltage: 230v 50Hz

Maximum Load Rating: Halogen; 1000W

Maximum Current Rating: 4.3A

Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²

Terminal (Earth) Diameter: 3.3mm; Capacity: 3 x 1.5mm²

Intended Applications: Indoor Use Only. Domestic lighting circuits.

Safety Advice: Not suitable for wire-wound low voltage transformers, fluorescent lighting, motors or fans. Do not overload.

Applicable Safety Standard: BS EN 60669-2-1

Commodity Code: #N/A

Declaration of Conformity

Product Features

  V-Dim dimming technology

  Ideal for mains and low voltage halogen lighting

  Overload protection that automatically switches off the lights when an overload is detected

  Sleek, low-profile screwless plate

Screwless Collection
Each finish is presented on low profile screwless faceplate, with hidden fixings contributing to an understated aesthetic. The Screwless Metal faceplates are expertly manufactured in the UK to the highest standard.

Polished Brass Finish
The elegant Polished Brass finish features matching polished brass rockers with an option of black or white inserts. Varilight?s decorative wiring accessories are British made and covered by the Varilight lifetime guarantee.
