Data Sheet
Product Code: YT40DC12
Product Description: 230V AC to 12V DC Dimmable Driver for LED Strip (max 40W)
Product Category: Drivers and Transformers
Insert/Knob Colour:
Barcode: 5021575194180
Dimensions: 167x54x26mm
Net Weight: 178g
Gross Weight: 180g
Fixing Centres: N/A
Depth from Mounting Face:
Recommended Back Box Depth: N/A
Operating Voltage: 230v 50Hz
Maximum Load Rating: 40W
Maximum Current Rating: 230V AC: 0.2A / 11.5V AC: 3.5A
Terminal (Live) Diameter: N/A; Capacity: N/A
Terminal (Neutral) Diameter: N/A; Capacity: N/A
Terminal (Earth) Diameter: N/A; Capacity: N/A
Product Features
Dimmable power supply for 12V d.c LED strip up to a maximum of 40W
Enhanced performance with all 12V LED lamps up to a maximum of 30W
Auto-resetting overload protection and over-temperature
Short circuit protection
Intended Applications: Indoor Use Only. Domestic lighting circuits.
Applicable Safety Standard: EN 61347-1, EN 61347-2-2, EN 61547, EN 55015 & EN 61000-3-2
Commodity Code: 85043180
All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of Issue: 25th January 2025 © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
