Data Sheet
Product Code: XOFIW
Product Description: 10A Fan Isolating Switch (3 Pole)
Range: Value
Finish: Polar White
Product Category: Rocker Switches
Insert/Knob Colour: White Insert
Barcode: 5021575050103
Dimensions: 85x85x25mm
Faceplate Depth: 5mm
Net Weight: 146g
Gross Weight: 148g
Fixing Centres: 60.3mm
Depth from Mounting Face:
Recommended Back Box Depth: 25mm
Operating Voltage: 230v 50Hz
Maximum Load Rating: 10A
Maximum Current Rating: 10A
Terminal (Live) Diameter: 3.3mm; Capacity: 3 x 1.5mm²
Product Features
Triple pole switching
Wide rocker for easy operation
Durable white plastic faceplate is anti-bacterial and fully biodegradable
Value Collection
The Polar White plastic range offers exceptional value. Push-fit screw covers give the face plate a uncomplicated aesthetic at an affordable price point.
Intended Applications: Indoor Use Only. Domestic power supply.
Applicable Safety Standard: BS EN 60669-1
Commodity Code: 85365007
