Instruction leaflet PDF

Data sheet: WDN2S

2-Gang Matrix Kit For Rotary Dimmers, Screwless Satin Chrome (WDN2S)

Data sheet

WDN2S 2-Gang Matrix Kit For Rotary Dimmers

Name: 2-Gang Matrix Kit For Rotary Dimmers
Brand: VARILIGHT
SKU: WDN2S

HDN2S is no longer made: the same is made now with WDN2S + MTR250 x 2.

Range Screwless Finish Satin

Product features

The Matrix system gives you complete dimming flexibility
Any combination of dimmers you can imagine, on one plate
Kit includes the faceplate, knobs, nuts and a nut spinner, everything except the dimmer modules
Dimmer modules purchased separately, so you only pay for what you use
Takes size S modules (Wi-Fi module on the white plate only), up to 400W of LED across the plate
The same modules replace the dimmer modules in existing VARILIGHT plates
Screwless low profile faceplate, just 4mm deep with no visible fixings

Product

Product code: WDN2S
Category: Dimmer Faceplate Kits
Range: Screwless
Finish: Satin
Insert / knob colour: Satin Knob
Barcode: 5021575293371

Size and fitting

Dimensions: 86x86x*mm
Faceplate depth: 4mm
Fixing centres: 60.3mm
Depth from mounting face: Module Dependent
Net weight: 126g
Gross weight: 128g

Electrical

Operating voltage: 230V 50Hz
Terminal (Earth): 3.3mm, capacity 3 x 1.5mm²

Safety and compliance

Intended applications: Indoor Use Only. Domestic lighting circuits. Do not use masking tape on any decorative products, or install on damp plaster.
Safety advice: Product Must Be Earthed.
Applicable safety standard: BS EN 60669
Commodity code: 85389091

Declaration of Conformity

Screwless collection

Screwless Low Profile: minimalist design with clip-on faceplates and hidden fixings for a smooth, modern look.

Satin finish

The Satin finish has a subtle sophistication with its soft sheen and understated elegance, which will enhance most interior design schemes. Black or white inserts blend seamlessly, with polished chrome rockers for a luxury feel.

All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of issue: 21st October 2026. © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
