Data sheet: XV5UACW

Double Socket with 20W Shared USB A & C Charging Ports, Classic Victorian Brass (XV5UACW)

Data sheet

XV5UACW Double Socket with 20W Shared USB A & C Charging Ports

Range Classic Finish Victorian Brass

Product features

20W shared between the USB-A and USB-C ports
Power Delivery 3.0 and Qualcomm Quick Charge 3.0 fast charging
Use any USB-A or USB-C cable
Both sockets stay free for other appliances
Able to switch off for added safety and power saving
Dual earth terminals for a secure earth connection
Bevel-edge faceplate, 8mm deep with brass screws, fits a 25mm back box

Product

Product code: XV5UACW
Category: Sockets with USB A Charging
Range: Classic
Finish: Victorian Brass
Insert / knob colour: White Insert
Barcode: 5021575009347

Size and fitting

Dimensions: 91x150x31mm
Faceplate depth: 8mm
Fixing centres: 120.6mm
Depth from mounting face: 18.5mm
Recommended back box depth: 25mm
Net weight: 200g
Gross weight: 202g

Electrical

Operating voltage: 230V 50Hz
Maximum load rating: USB: 20W
Maximum current rating: 13A
Terminal (Live): 4.8mm, capacity 4 x 2.5mm²
Terminal (Neutral): 4.8mm, capacity 4 x 2.5mm²
Terminal (Earth): 4.8mm, capacity 4 x 2.5mm²

Safety and compliance

Intended applications: Indoor Use Only. Domestic power supply. Do not use masking tape on any decorative products, or install on damp plaster.
Safety advice: Please note recommended back box depth relies on efficient cable routing. Product Must Be Earthed.
Applicable safety standard: BS 1363-2
Commodity code: 85366990

Declaration of Conformity

Classic collection

The Classic range is a contemporary take on a raised profile faceplate. The bevel-edge design is a timeless style, which will pair beautifully with any interior.

Victorian Brass finish

For a polished look, the Victorian Brass finish makes a perfect choice with classic styling and clean lines. Choose from black, white or matching polished brass rockers.

All information is subject to change without notice. Errors and omissions excepted. Images are for illustrative purposes only. Individual features and colours may vary. Refer to date of issue to identify latest version.
Date of issue: 11th November 2026. © Doyle & Tratt Products Ltd, Carylls Lea, Faygate, West Sussex, RH12 4SJ, United Kingdom. All rights reserved.
